Technical Datasheet
Nominal diameter::
DN 50 - DN 300
Face-to-face::
EN 558 Series 20
ISO 5752 Series 20
API 609 Table 1
ISO 5752 Series 20
API 609 Table 1
Flange accommodation::
EN 1092 PN 6/10/16
ASME Class 150
AS2129 T/E
AS4087 CL16
ASME Class 150
AS2129 T/E
AS4087 CL16
Flange Surface Design::
EN 1092 Form A/B
ASME RF, FF
ASME RF, FF
Top flange::
EN ISO 5211
Marking::
EN 19
Tightness check::
EN 12266 (Leakage rate A)
ISO 5208, Category 3
ISO 5208, Category 3
Temperature range::
- 10°C to +120°C
(depending onpressure, medium and material)
(depending onpressure, medium and material)
Max. Operating pressure::
max. 19,2 bar
Vacuum::
0,1 bar absolute
